ACO Engineering Pumps End Suction Pumps are single-stage, single-suction centrifugal pumps designed for a wide range of applications. These pumps feature a back-pull-out design that allows for easy maintenance without disturbing the piping connections. Built with high-quality cast iron or stainless steel construction, the End Suction Pump delivers reliable performance for water supply, HVAC, industrial process, and chemical applications. The open impeller design handles clear liquids and light slurries with high efficiency, while the enclosed impeller option is available for higher head requirements.
| Capacity | Up to 2,000 m³/h |
|---|---|
| Head | Up to 160 m |
| Power Range | 0.55 – 250 kW |
| Temperature | -20 °C to +120 °C |
| Suction Size | 32 mm to 400 mm |
| Discharge Size | 25 mm to 350 mm |
| Speed | 1,450 / 2,900 rpm (50 Hz) / 1,750 / 3,500 rpm (60 Hz) |
| Material | Cast iron, stainless steel, bronze |
| Applications | Water supply, HVAC, industrial process, chemical |
